Efergy

Efergy XL CT Sensor (19mm) 200 Amp

Efergy XL Large Sensor with 3.5mm Jackplug Fitting

Efergy

Efergy XL CT Sensor (19mm) 200 Amp

Efergy CT Sensor XL with Jackplug Fitting suitable for most Efergy Elite, E2 and Ecotouch Electricity Monitors as well as the Efergy Engage Internet Hubs
The large sensor is required for use on cables that are larger 12mm and up to 19mm diameter. They are also suitable for more powerful electrical installation up to 200 amps per phase.
How it Works:
Efergy transmitters come with three spaces for sensors. Just look on the underside of the transmitter, take out the rubber cover of one of the spare spaces and plug in your large sensor. Then attach it the same way as the previous one.

Specification:

  • Model: XL-SR
  • Dimensions: 38x51x38mm
  • Weight: 60g
  • Internal diameter: Max. 19mm
  • Nominal: 120A Max. 200A
  • Voltage Range: 110V-300V
  • CAT II 600V
    SKUEGY0007
    £0.00
    £13.99
